All Spec
PANEL
-
Screen Size (Inch)
-
65
-
Panel Technology
-
IPS
-
Back Light Type
-
Direct
-
Aspect Ratio
-
16:9
-
Native Resolution
-
3840 x 2160 (UHD)
-
Refresh Rate
-
60Hz
-
Brightness
-
390nit (Typ., without Glass)
-
Contrast Ratio
-
1,200:1
-
Dynamic CR
-
NO
-
Color Gamut
-
NTSC 68%
-
Viewing Angle (H x V)
-
178º x 178º
-
Color Depth (Number of Colors)
-
1.07 Billion colors
-
Response Time
-
8ms (G to G)
-
Surface Treatment (Haze)
-
Haze 25%
-
Life time
-
30,000Hrs (Min.)
-
Operation Hours (Hours/Day)
-
16/7
-
Portait / Landscape
-
NO / YES
CONNECTIVITY
-
HDMI In
-
YES (3ea)
-
HDMI In (HDCP Ver.)
-
2.2/1.4
-
DP In
-
NO
-
DVI-D In
-
NO
-
RGB In
-
YES
-
Audio In
-
YES
-
RS232C In
-
YES
-
RJ45(LAN) In
-
YES (1ea)
-
IR In
-
NO
-
USB In
-
USB3.0 Type A (3ea), USB2.0 Type A (3ea)
-
HDMI Out
-
NO
-
DP Out
-
NO
-
Audio Out
-
YES
-
Touch USB
-
USB2.0 Type B (2ea)
-
External Speaker Out
-
NO
-
RS232C Out
-
NO
-
RJ45(LAN) Out
-
NO
MECHANICAL SPECIFICATION
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L/B : 18.9/18.9/18.9/45.7mm
-
Weight (Head)
-
38.8Kg
-
Packed Weight
-
48.5Kg
-
Monitor Dimensions (W x H x D)
-
1489 x 897 x 87mm
-
Carton Dimensions (W x H x D)
-
1628 x 1005 x 208mm
-
Handle
-
YES
-
VESA Standard Mount Interface
-
600 x 400 mm
FEATURE - HARDWARE
-
Internal Memory (eMMC)
-
32GB
-
Wi-Fi/BT (Built-in)
-
YES
-
Temperature Sensor
-
NO
-
Auto Brightness Sensor
-
NO
-
Power Indicator
-
YES
-
Local Key Operation
-
YES
FEATURE - SOFTWARE
-
Booting Logo Image
-
YES
-
PIP
-
NO
-
PBP
-
NO
-
Screen Share
-
YES
-
Setting Data Cloning
-
NO
-
Crestron Connected
-
NO
-
Smart Energy Saving
-
NO
-
PM mode
-
NO
-
Wake on LAN
-
NO
-
Network Ready
-
NO
-
HDMI-CEC
-
YES
ENVIRONMENT CONDITIONS
-
Operation Temperature
-
0 °C to 40 °C
-
Operation Humidity
-
10 % to 80 %
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-in Power
POWER CONSUMPTION
-
Typ.
-
180W
-
Max.
-
300W
-
BTU (British Thermal Unit)
-
614 BTU/Hr(Typ.), 1024 BTU/Hr(Max.)
-
DPM
-
0.5W
-
Power off
-
0.5W
SOUND
-
Speaker (Built-in)
-
YES (10W x 2)
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "A" / CE
-
ERP / Energy Star
-
YES / NO
OPS COMPATIBILITY
-
OPS Type compatible
-
YES (Slot)
-
OPS Power Built-in
-
YES
SOFTWARE COMPATIBILITY
-
Connected Care
-
NO
LANGUAGE
-
OSD
-
English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian
ACCESSORY
-
Basic
-
Power Cord 3M*1, USB Cable (Type A-Type B) 5M*1, HDMI Cable 3M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
-
Optional
-
NO
SPECIAL FEATURE
-
Conformal Coating (Power Board)
-
YES
DEDICATED FEATURE - TOUCH
-
Available Object Size for Touch
-
Ø3 mm ↑
-
Response Time ('Paint' app on Windows 10 PC)
-
10ms ↓
-
Accuracy (Typ.)
-
±2.0mm
-
Interface
-
USB2.0
-
Protection Glass Thickness
-
4mm (Anti-Glare)
-
Protection Glass Transmission
-
0.87
-
Operating System Support
-
Windows 7/8/10/XP/Linux/Mac/Android (Windows XP/Linux/Mac Support one point touch)
-
Multi Touch Point
-
Max. 20 Points
DEDICATED FEATURE - CREATE BOARD
-
CPU
-
Dual core A73+Dual core A53
-
GPU
-
Dual Core Mail G51
-
Memory(RAM)
-
3GB
-
Storage
-
32GB
-
Wi-Fi
-
802.11a/b/g/n/ac
-
LAN
-
Gigabit LAN
-
Bluetooth
-
Bluetooth 4.0
-
OS ver. (Android)
-
Android 8
