All Spec
PHYSICAL PARAMETER
-
Pixel Configuration
-
Single SMD
-
Pixel Pitch (mm)
-
2.5
-
Module Resolution (W x H)
-
120 × 90
-
Weight per Module (kg)
-
0.59
-
Module Dimensions (W x H, mm)
-
300 × 225
-
No. of Modules per Cabinet (W × H)
-
4 × 3
-
Cabinet Resolution (W × H)
-
480 × 270
-
Cabinet Dimensions (W × H × D, mm)
-
1,200 × 675 × 51
-
Cabinet Surface Area (m²)
-
0.81
-
Weight per Cabinet (kg/cabinet)
-
22.5
-
Weight per Square Meter (kg/m²)
-
27.8
-
Physical Pixel Density (pixels/m²)
-
160,000
-
Flatness of Cabinet (mm)
-
±0.5
-
Cabinet Material
-
Die-casting Aluminum
-
Service Access
-
Front
OPTICAL PARAMETER
-
Max Brightness (nit)
-
600
-
Colour Temperature (K)
-
3,200-9,300
-
Visual Viewing Angle (H×V)
-
160 × 160
-
Brightness Uniformity
-
95%
-
Colour Uniformity
-
±0.015Cx,Cy
-
Contrast Ratio
-
Typ. 5,000 : 1 / Peak. 9,000 : 1
-
Processing Depth (bit)
-
20 (HDR10, HDR10 Pro)
ELECTRICAL PARAMETER
-
Power Consumption (W/cabinet, Max.)
-
290
-
Power Consumption (W/cabinet, Avg.)
-
190
-
Power Consumption (W/m², Max.)
-
358
-
Heat Dissipation (BTU/h/Cabinet, Max.)
-
990
-
Heat Dissipation (BTU/h/Cabinet, Avg.)
-
648
-
Heat Dissipation (BTU/h/m², Max.)
-
1,222
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
3,840
OPERATION CONDITIONS
-
Lifetime (Half Brightness)
-
100,000
-
Operating Temperature (°C)
-
0°C to +40°C
-
Operating Humidity
-
10-80% RH
-
IP Rating Front
-
IP20
-
IP Rating Rear
-
IP20
CERTIFICATION
-
Certification
-
Safety 60950-1, EMC Class B, BS476 Part7 Class1
ENVIRONMENT
-
Environment
-
RoHS
CONTROLLER
-
Controller
-
CSAC-025K
