All Spec
OPTICAL PARAMETERS
-
Pitch
-
3.3 mm
-
LED Type
-
SMD
-
Pixels per LED Module
-
8,640
-
Aspect Ratio (per Cabinet)
-
64 : 90
-
Resolution (per Cabinet)
-
192 × 270
-
Pixels (per Cabinet)
-
51,840
-
Pixel Density (per SQM)
-
90,000
-
Frame (Video) Rate
-
24 Hz, 25 Hz, 30 Hz, 48 Hz, 50 Hz, 60 Hz
-
Brightness (After Calibration)
-
48 nit (DCI-compliant)
-
Contrast Ratio
-
4000 : 1 (Minimum)
-
Color Space (Gamut)
-
DCI - P3 (DCI-compliant)
-
Viewing Angle (Horizontal, Vertical)
-
120º, 120º
-
Color Depth
-
12 Bit (DCI-compliant)
-
Chromaticity Uniformity
-
In case of White : Within ±0.015 x, ±0.015 y
-
Color Temperature (White)
-
(x. y) = (0.314, 0.351) / DCI-P3 Theater
-
Color Temperature (R, G, B)
-
DCI-P3 theater R: (x. y) = (0.68, 0.32)
G: (x. y) = (0.265, 0.690)
B: (x. y) = (0.15, 0.06)
-
Lifetime
-
100,000 Hours (LED to Half Brightness)
-
Operation Hours
-
16 Hours per Day / 7 Days per Week
PHYSICAL/ELECTRICAL PARAMETERS
-
Modules (per Cabinet)
-
6 (2 × 3)
-
Dimension (LDM)
-
320 mm × 300 mm
-
Dimension (per Cabinet)
-
640 mm × 900 mm × 124 mm (Including Handle)
-
Dimension (4K, Total)
-
14,080 mm × 7,200 mm (101 sqm)
-
Dimension (4K, Active Area)
-
13,653 mm × 7,200 mm (98 sqm)
-
Weight (per Cabinet)
-
15 kg
-
Weight (4K, Total)
-
2,640 kg
-
Material of Cabinet Body
-
Aluminum
-
Heat Generation (per Cabinet)
-
221 BTU (Max.) / 73 BTU (Typ.)
-
Serviceability
-
Rear only
-
Power Supply
-
AC100-240 V ~, 50/60 Hz
-
Power Type
-
Built-in Power
-
Power Consumption (Max, per Cabinet)
-
90 watt (Main) / 52 watt (Secondary)
-
Power Consumption (Max, 4K)
-
9,260 W
-
Certification
-
DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
-
Supported Media Server
-
Dolby® IMS3000
-
Interface
-
RJ45
-
Operation Temperature
-
0°C to 40°C
-
Operation Humidity
-
10% to 80%
-
Storage Temperature
-
-20°C to 60°C (-4°F to 140°F)
-
Storage Humidity
-
5% to 85%
