All Spec
GENERAL
Power Consumption
Networked standby: 2.0 W
AC adapter
Model: MS-Z2610R230-065E0-P Manufacturer: MOSO POWER SUPPLY TECHNOLOGY CO., LTD. Input: 100 - 240 V ~ 50/60 Hz Output: 23 V = 2.61 A
Dimensions (W x H x D)
Approx. 975.0 mm x 63.0 mm x 125.0 mm (including the base)
Operation Temperature Range
5 °C - 40 °C
Operation Humidity Range
5 % - 80 % RH
Bus Power Supply (USB)
5 V = 500 mA
Available Digital Input Audio Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format
Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos, DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X, IMAX DTS, IMAX DTS:X, PCM
INPUT/OUTPUT
OPTICAL IN
3.0 V (p-p), (optical audio connection terminal) × 1
HDMI™ IN
19-pin (Type A, HDMI™ connection terminal) × 1
HDMI™ -> TV (eARC / ARC)
19-pin (Type A, HDMI™ connection terminal) × 1 4K resolution is supported for 4K sources applied with HDCP 2.3.
AMPLIFIER(RMS OUTPUT)
Total
400 W RMS
Front
30 W RMS × 2 (Impedance: 6 Ω, THD 10 %)
Centre
30 W RMS (Impedance: 6 Ω, THD 10 %)
Top (Overhead)
30 W RMS × 2 (Impedance: 6 Ω, THD 10 %)
Top centre (Overhead)
30 W RMS (Impedance: 6 Ω, THD 10 %)
Subwoofer
220 W RMS (Impedance: 3 Ω, THD 10 %)
WIRELESS SUBWOOFER
Power Requirement
Refer to the main label on the Wireless Subwoofer.
Power Consumption
Refer to the main label on the Wireless Subwoofer.
Type
1-way 1 speaker
Impedance
3 Ω
Rated power
220 W RMS
Max. Power
440 W RMS
Dimensions (W x H x D)
Approx. 221.0 mm x 390.0 mm x 313.0 mm
SYSTEM
Wireless LAN (Internet antenna)
802.11a/b/g/n Wi-Fi network compatible
REAR SPEAKERS
Type
1-way 1 speaker
Impedance
3 Ω
Rated power
70 W RMS
Max. power
140 W RMS
Dimensions (W x H x D)
Approx. 100.0 mm x 140.0 mm x 100.0 mm
